20 Plate Trailing Plough

$6,000.00

Disc Plough 20 Disc Trailing Plough is a heavy duty (10 front discs and 10 rear discs) 660mm diameter cuts 1900 wide track. Fitted with hydraulic wheel lift and suitable for tractors from 70hp to 100hp I. This series of 18/20/24/28/32 heavy duty dragging disc offset harrow are designed for field work. From breaking hardened and impervious solid surface, crushing and spreading straw, shattering soil after tillage. Helps in preparing the land and preserving soil moisture. It can be used on cultivated land as a tillage harrow instead of ploughing. They offer high harrowing capacity with reasonable utilization of power, great ability to cut and shatter the soil, level soil surface and loosen soil after harrowing. They are well adaptable for heavy clay soil wasteland and weedy field as well.
The harrows are designed from a combined structure of rigid rectangle frame and welded tube, equipped with hydraulic up and down road wheel spring leveling device. Quality sealed bearing with spheroidal outer surface and square inner hole special for disc harrows.
These machines are easy to move with small turning radius and easy to adjust and maintain.

Category:

Description

20 Plate Trailing Plough

Specifications

Model 1BZ-2.2
Length 5200 mm
Width 2570 mm
Height 1340 mm
Weight 1250 Kg
Working width 2200 mm
Disc pitch 230 mm
Disc diameter 660 mm
Max. working depth 200 mm
Max. adjusting angle (F/R) 23 degrees
Harrowing capacity 1.3 Ha/Hr
